Suitable to Process | Galvanized steel strip and color coated steel strip |
Width of raw material | customized |
Rollers | Cr12 |
Dimensions | About 10000*900*1300mm |
Power | 4+5.5kw |
Thickness of sheet | 0.25-0.6mm as usual;customized |
Material of cutting blade | Cr12 |
Diameter of the roller | customized |
Voltage | 380V, 50Hz, 3 phrases;customized |
weight | About 6.0T |
Productivity | 20—-25m/min |
Control system | Automatically controlled by computer |
This producing line is maintained free of charge for 18 months. When the machine is used in China, we will install and debug the machine for free; if it is used at abroad, we will send the professional technician to debug. Buyers should take all the fees for technicians traveling abroad.
